Product description |
|
|
Place of Origin |
SUIZHOU, CHINA |
|
Brand Name |
CLW |
|
Certification |
CCC, SGS, BV, DOT, GCC |
|
Model Number |
CLW5120 |
|
Payment & Shipping Terms |
|
|
Minimum Order Quantity |
1 |
|
Unit Price |
Negotiable |
|
Packaging Details |
naked,waxed,bulk ship,ro-ro |
|
Delivery Time |
30-35 days |
|
Payment Terms |
L/C, D/A, D/P, T/T, Western Union, MoneyGram |
|
Supply Ability |
500 Unit/Month |
Road sweeper truck mainly used for ground cleaning, road curb edge cleaning, road curb cleaning and ground watering. It is suitable for various climates and different road surfaces for cleaning operations. It is more suitable for cleaning and dust removal in places such as squares, highways, residential areas, parking lots, docks, airports, stations, cement plants, power plants, etc.
Dongfeng 5m3 road sweeper truck parameters:
| outer diameter | 6200*2000*2590mm | GVW | 7360kg |
| curb weight | 5100kg | rated loading capacity | 2130kg |
| axle loading capacity | 2640/4720mm | passengers | 2 |
| max speed | 110km/h | emission standard | EURO 6 |
Dongfeng 5m3 road sweeper truck body parameters:
| Water tank | water tank volume | 1.5 m³ |
Waste tank | Waste tank volume | 4 m³ |
Waste tank tilting angle | ≥46° | |
Discharge door opening angl | ≥85° | |
Auxiliary engine | Brand | JMC |
Power | 87hp | |
Hydraulic system | Type | electrical control |
Main components | Gear pump, hydraulic motor, hydraulic cylinder, electromagnetic valve | |
Pressure | 16 MPa | |
Hydraulic oil tank volume | 60L | |
Hydraulic oil temperatur | 60 ˚C | |
Electric system | typ | DC12 V |
Voltage | 12V | |
Battery | 12V | |
Water spraying system | Main components | Electric diaphragm pump, water filter, nozzle, etc. |
Sweeping device | type | equipped with 4 rotating sweeping discs in the middle, driven by a hydraulic motor. The right front part can be independently controlled and has a function for avoidance and recovery. |
Diameter of the sweeping disc | 850 mm | |
Sweeping disc angle | Inclination: 4 - 6 degrees Outward tilt: 4 - 7 degrees | |
Suction disc | type | Single suction port, hydraulic control, spring suspension. |
Diameter of the suction port | 200mm | |
Sweeping performance | Efficiency | ≥95% |
Maximum inhalation particle size | 120 mm | |
Seeping width | 2.6 m | |
Max sweeping capacity | 13000㎡/h-52000㎡/h | |
Extension size of the sweeping disc | ≥400 mm | |
Speed while sweeping | 3-20 km/h |
